Vertical Food Weighing Filling Pouch Packaging Machine 2.2kw Multifunction

Product Categories
JIANGSU HAITEL MACHINERY CO.,LTD
Contact Now

Vertical Food Weighing Filling Pouch Packaging Machine 2.2kw Multifunction

  • 1
  • 2

Brand Name : Haitel

Model Number : HTL-V420

Certification : CE/ISO9001

Place of Origin : Jiangsu Province,China

MOQ : 1 sets

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 5 sets per month

Delivery Time : 50 days

Packaging Details : Sea-Worthy Packing or Air-Worthy Packing

Packing speed : 5-60bags/min

Total power : 2.2kw

Volatge : 380V 50HZ

Dimension : 1320*950*1360mm

Automatic grade : Automatic

After-sales service provided : Engineers available to service machinery overseas

Condition : New

Warranty : 1 year

Type : Multi-Function Packaging Machine

Contact Now

Product Description

Vertical Automatic Food Weighing and Filling Pouch Packaging Machine 2.2 kw

Application:

The bagging machine is widely used for packing of products in shape of granules, stripes, slices, such as candy, potato chips, jelly, and peanuts.

Characteristics:

1. Touch screen with stable transmitting PLC control to perform bag making, weighing, filling, sealing, code printing, and cutting automatically.

2. Independent compressed air control and electrical wire system control separately, low noise in running, stable performance.

3. Vacuum belt pulling system to feed film and make bags with no faults.

4. Double servo control system, precise positioning.

5. Easy to palce the rewind rolls onto the machine.

6. Set uo and adjust parameters on touch screen to change bag size.

7. Sealed structure design to prevent dust contamination.

8. Multi computerized weighing heads to deliver correct weight.


Specifications:

Mode HTL-V420 HTL-V520 HTL-V680
Bag length(mm) 80-300(L) 80-400(L) 100-480(L)
Bag width(mm) 50-200(W) 80-250(W) 180-320(W)
Max width of roll film(mm) 420 520 680
Packing speed(bags/min) 5-60 5-50 5-50
Volumn range 150-1200ml 3000Max 6000Max
Air consumption(Mpa) 0.65 0.65 0.65
Gas consumption(m3/min) 0.3 0.4 0.4
Power voltage 220V 220V 220V
Power(KW) 2.2 4 5
Dimension(L*W*H)mm 1320*950*1360 1150*1795*1650 1780*1350*1950
Weight(kg) 540 600 900

Vertical Food Weighing Filling Pouch Packaging Machine 2.2kw Multifunction

Vertical Food Weighing Filling Pouch Packaging Machine 2.2kw Multifunction

Packing Samples:

Vertical Food Weighing Filling Pouch Packaging Machine 2.2kw MultifunctionVertical Food Weighing Filling Pouch Packaging Machine 2.2kw Multifunction

Packaging & Shipping

Vertical Food Weighing Filling Pouch Packaging Machine 2.2kw Multifunction

1. Product production is completed, by the quality inspection department to check.

2.After inspection qualified, clean for whole machine.

3.Packing:

a. Inside the machine put desiccant.

b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap.

c. On wood packaging on the outside of the machine, then use metal reinforcement with steel.

4.Container:according to different products for reinforcement.
